"Exact Spec" Evaporator Replacements for SubZero Refrigerators

Better Quality evaporators, made of less corrosive metals then in the past, meaning they should last much longer!

RefrigeratorPartReplacements.com has made sure that the exact size specs of the OEM are maintained,
to fit the listed Model# refrigerators, using Superior Refrigeration, 99% Pure Aluminum material,
resulting in a much less corrosive evaporator than have been available in the past,
which should lend to many more years of life, than the oem evaporators,
at a fraction of the oem price!

How do I know if my refrigerator evaporator is leaking?
The Classic Symptom of a leaking evaporator:
Ice Formation, covered by frost, on the inside back wall(left pic)
Evaporator capillary inlet, freezing up, with back wall removed(right pic)
Notice the exact location, in both pics above, of the frost and ice buildup.
The rest of the evaporator is void of any freon flowing through it, which is why you can
see the silver look of the tubing, after, and below the frost. The point where the frost is
built up, is the farthest that the freon is flowing due to a great loss in freon, because
the evaporator is likely leaking, which also causes all the oil from the compressor
to be pumped down, into the evaporator, and with a leak in the evaporator, the oil
pools up and collects in the evaporator, and restricts it, and the compressor cannot
suck the oil back up to the compressor, so the compressor runs low on oil, or without
oil, and overheats the compressor, causing damage to it internally, or it locks up.
Now the evaporator & compressor, both need to be replaced, along with the
filter/drier, to get the refrigerator back into normal operationg condition.
If you suspect that the compressor has been running a long time, weeks or months,
low on freon, and the oil pooling into the evaporator, then you will need
to order the evaporator, for your Model#, on this page, as well as the filter/drier,
and also the corresponding compressor for your Model#, which you can find here
to complete the repair properly, or it is likely the compressor will fail, soon after.
If your system is an R12 system, it will be updated to the new Freon standard using
R134a(and the entire system MUST be evacuated, flushed/cleaned, to rid it
of any previous R12 oil residue or particulants).
Converting to R134a, is general practice, since 1991, since R12 is not used anymore,
during part replacement, and recharge, of any R12 systems!
Some techs are using 414b(hotshot), 414a(causes a slight whining noise most techs say),
which is not recommended by AHAM or any Freon Authority.

IMPORTANT - READ BEFORE ORDERING!!!
We have been in the Appliance Repair Business over 36+ years
, so we are very aware that evaporators
are considered an emergency replacement item, since we have personally replaced hundreds, if not thousands of them.
Most of the time you can recharge the system, to get the customer by, until you receive the evaporator.


"Exact Spec"
Evaporator Replacements for SubZero Refrigerators
Don't fall into this same trap, by having inexperienced techs install your evaporator!

Installation by ONLY Qualified/Licensed/Experienced Techs
to Avoid disastrous results like these below:
Experienced/Qualified Techs know, Brazing Capillary & 3/8" tubes:
Use Acetylene(1500-1700 degs)ONLY, NOT Oxy-Acetylene torch(3000 degs)!

Mr Leonard's,
Inexperienced Technician, Screw-up!


Mr Leonard sent evaporator back,
claiming it had a leak in it!
The leak was in this disastrous solder joint,
not the evaporator!

Rod Bartz, RB Appliance
stated evaporator was poor quality
!

Self-proclaimed 40 yr tech, Rod Bartz
claimed evaporator was not made of copper
which is why the aluminum joint melted
No Evaporators are made of copper!
ALL Evaporators are Aluminum, w/copper inlets!

Too much heat on copper inlets,
discolored, bubbled paint, melted aluminum joint!
-------------------------------------------------------------
NO REFUNDS FOLKS!

Get a Qualified and Experienced Tech to install the evaporator!
Handymen, and the Average Customer is NOT who should try to replace the evaporator!
Do NOT think you can watch a youtube video to do this job!
It is suggested that you DO NOT CALL ANY SubZero AUTHORIZED SERVICE COMPANY!
ONLINE REVIEWS STATE THEY have been known to Severely Overcharge Customers,
and they also will NOT INSTALL AN EVAPORATOR YOU PURCHASE, and ask them to install!

To Find an Independent Service Company...
click here: Independent Service Company Locator


Every single Evaporator is Leak/Pressure Tested Thoroughly
before being shipped out to you!
So, if you have a leak after installation, check your brazing joints,
because you left a leak, which is very common, even for experienced techs!

Evaporators are Not to be installed by just anyone,
but ONLY by a Licensed, Experienced and Qualified sealed system service technician!
There are No Refunds, for incorrect installation and damage to the evaporator!

Replacement Evaporators for SubZero Refrigerators!
(Redesigned & Newly Manufactured to be Superior Quality to the OEM!)

Below are the evaporators we have available at this time, the most common and popular ones:

"Exact Spec" Replacement Evaporators for SubZero Refrigerators Index
click on your SubZero Model# or Refrigerator Evaporator Part#
below to go to that specific evaporator
SubZero Model#'s:

Refrigerator Evaporator Part#'s:

501R

7014701PR

561, 427, 430

4204440PR

550, 650

4204400PR

501R, 601R, 601RG-2/3, 601RG-2/3

4204410PR

511, 532, 590, 611, 632, 690, 695-2

4204420PR

542, 580, 642, 680

4204430PR


Installation Instructions

Right click and "Save As"

Looking for a Freezer Evaporator for your unit?
Contact us with your Model & Serial# for your Freezer unit
Contact Us here

Evaporator
SubZero Model
Specs
USA Only
Buy Now!



Refrigerator/Freezer
UV Dye Filter/Drier
Replacement for
OEM 7006964

  • 100% XH-9 Beaded desiccant
  • Compatible with all new and existing refrigerants and oils.
  • Reduces wear & tear on component parts
  • Maximum working pressure 500psi.
  • Use on capillary or expansion valve systems.
  • Hermetically sealed, directional flow with access valve.
  • Copper shells and end tubes.
  • 100 Micron filter sieve.
  • Easy break off grooved ends.
  • Reduces clogged capillary tubes.
  • Magnetic reduction filter reduces microscopic steel, iron, & stainless steel particles as the refrigerant passes through the system.

IN STOCK
USA ONLY
On Sale: $13.95
$16.95


Accumulator
7015937
Accumulator
501R, 501F, 601F, 601F-2
Not used with all Serial Dates
Check 1st to make sure you need it

$49.65



7014701PR Evaporator

Replaces Part# 3130240

501R
Use Prior to Serial #1004775
Except Between
#M959920 to M960169

Starting w/Serial #1004775
& Between #959920-#960169
Use Pt# 4204410

Accumulator for:
501R, 501F, 601F, 601F-2

Not used with all Serial Dates
Check 1st to make sure you need it
Use Part# 7015937


Installation Instructions

Right click and "Save As"

501R Parts Manual Link

Make sure you are ordering the proper evaporator.
There are No Refunds!

MUST BE INSTALLED BY LICENSED & QUALIFIED TECHNICIANS OR WARRANTY VOID!

Due to this evaporator being considered oversized by the USPS, the shipping rate is slightly higher, than the smaller sized evaporators.

Dimensions:
29" wide
20" tall
1" deep
IN STOCK
USA ONLY
On Sale: $155.00
Retail: $215.00
SubZero OEM Price: $243.26

Normal Shipping
(4-7 days)


*NEW* - RUSH
Priority Shipping

(2-3 day)



4204410PR Refrigerator Evaporator
Replaces Part# 3130390

501R, 601R, 601RG-2/3, 601RG-2/3

501R
Use Starting w/Serial #1004775
& Between #959920-#960169

Prior to Serial #1004775
Except Between
#M959920 to M960169
Use Pt# 7014701

601R, 601R-2/3

Use Regardless of Serial#

601RG-2/3
Use Regardless of Serial#


Installation Instructions

Right click and "Save As"

501R Parts Manual Link
601R Parts Manual Link
601RG Parts Manual Link

Make sure you are ordering the proper evaporator.
There are No Refunds!

MUST BE INSTALLED BY LICENSED & QUALIFIED TECHNICIANS OR WARRANTY VOID!

Due to this evaporator being considered oversized by the USPS, the shipping rate is slightly higher, than the smaller sized evaporators.

Dimensions:
28" wide
20" tall
1" deep
USA ONLY


Appliance Parts Depot
Buy from
APDepot
click Here


Fox Appliance Parts
Must setup Login
to order parts


Coast Appliance Parts
Buy from Coast
click here



4204440PR Refrigerator Evaporator
Replaces Part# 3130280
561/427/430
Use regardless of Serial#
427-2
, 430-2
Use Pt# 3130640


Installation Instructions

Right click and "Save As"

561 Parts Manual Link
427 Parts Manual Link
430 Parts Manual Link

Make sure you are ordering the proper evaporator.
There are No Refunds!

MUST BE INSTALLED BY LICENSED & QUALIFIED TECHNICIANS OR WARRANTY VOID!

Dimensions:
15" wide
12" tall
1" deep
IN STOCK
USA ONLY
On Sale: $105.00
Retail: $135.00

SubZero OEM Price: $160.00

Normal Shipping
(4-7 days)


*NEW* - RUSH
Priority Shipping

(2-3 day)



4204400PR Refrigerator Evaporator
Replaces Part# 3130270

550/650

550
Use Regardless of Serial#

650
Use Prior to Serial #2128097
Starting with #2128097
Use Pt# 7009366


Installation Instructions

Right click and "Save As"

550 Parts Manual Link
650 Parts Manual Link

Make sure you are ordering the proper evaporator.
There are No Refunds!

MUST BE INSTALLED BY LICENSED & QUALIFIED TECHNICIANS OR WARRANTY VOID!

Dimensions:
29" wide
8" tall
1" deep
USA ONLY
Appliance Parts Depot
Buy from
APDepot
click Here


Fox Appliance Parts
Must setup Login
to order parts


Coast Appliance Parts
Buy from Coast
click here



4204420PR Refrigerator Evaporator
Replaces Part# 3130260

511/532/590
611/611-2/632
632-2/690/695-2

---------------------------
511/532/590
611/632/690

USE REGARDLESS OF SERIAL#

532
USE REGARDLESS OF SERIAL#
Note: Prior to Serial #681566
an accumulator was used in production that Must be Discarded when evaporator is replaced

695-2
Use Prior to Serial #M2275455/#P2278219
Starting w/Serial# M2275455/ #P2278219
Use Pt# 7009366

611-2
Use Prior to Serial #2147190
Starting With Serial #2147190
Use Pt# 7009366

611G-2
Use Pt# 7009366

632-2
Use Prior to Serial #2128562
Starting With Serial #2128562
Use Pt# 7009366


Installation Instructions

Right click and "Save As"

511 Parts Manual Link

532 Parts Manual Link

590 Parts Manual Link

611 Parts Manual Link

632 Parts Manual Link
690 Parts Manual Link

695-2 Parts Manual Link

Make sure you are ordering the proper evaporator.
There are No Refunds!

MUST BE INSTALLED BY LICENSED & QUALIFIED TECHNICIANS OR WARRANTY VOID!

Dimensions:
24" wide
16" tall
1" deep
USA ONLY
Appliance Parts Depot
Buy from
APDepot
click Here

Fox Appliance Parts
Must setup Login
to order parts


Coast Appliance Parts
Buy from Coast
click here



4204430PR Refrigerator Evaporator
Replaces Part# 3130420

542 / 580
642 / 680

542
Use regardless of Serial#

642/642-2
Use Prior to Serial #2143499
Starting with Serial #2143499
Use Pt# 7009366

680/685-2
Use Prior to Serial #M2270483/#P2290992
Starting with Serial
#M2270483/#P22909926
Use Pt# 7009366


Installation Instructions

Right click and "Save As"

542 Parts Manual Link
642 Parts Manual Link
680 Parts Manual Link

Make sure you are ordering the proper evaporator.
There are No Refunds!

MUST BE INSTALLED BY LICENSED & QUALIFIED TECHNICIANS OR WARRANTY VOID!

Dimensions:
20" wide
16" tall
1" deep
USA ONLY
Appliance Parts Depot
Buy from
APDepot
click Here

Fox Appliance Parts
Must setup Login
to order parts


Coast Appliance Parts
Buy from Coast
click here



If you have any questions, please let us know.

Contact Email Address: Rtnoww@aol.com

Sorry, but we are so busy filling orders, we don't have time to answer the phone.
If you have questions, please email us.


click here to order your SubZero Switches Now!
Switches

click here to order your SubZero Evaporators Now!
Evaporators

On Sale!
click here to order your SubZero Heat Exchangers Now!
Heat Exchangers

NOW Available!
click here to order your SubZero Compressors Now!
Compressors

NOW Available!

RefrigeratorPartReplacements.com © 2013 All Rights Reserved



Sub-Zero Parts Sub-Zero Parts, sub-zero parts subzero parts, subzero refrigerator parts sub-zero refrigerator parts
Sub-Zero Parts Sub-Zero Parts, sub-zero parts subzero parts, subzero refrigerator parts sub-zero refrigerator parts
Sub-Zero Parts Sub-Zero Parts, sub-zero parts subzero parts, subzero refrigerator parts sub-zero refrigerator parts
Sub-Zero Parts Sub-Zero Parts, sub-zero parts subzero parts, subzero refrigerator parts sub-zero refrigerator parts
Sub-Zero Parts Sub-Zero Parts, sub-zero parts subzero parts, subzero refrigerator parts sub-zero refrigerator parts
Sub-Zero Parts Sub-Zero Parts, sub-zero parts subzero parts, subzero refrigerator parts sub-zero refrigerator parts
Sub-Zero Parts Sub-Zero Parts, sub-zero parts subzero parts, subzero refrigerator parts sub-zero refrigerator parts
